Diamox AR1617 – Transparent Anti-Reflective Film (Linear Mtr)

From: £141.09

Diamond Coatings also offer a wide range of coated films and we have now extended our film product range, to offer a high quality Transparent Anti-Reflective (AR) film, which we can provide by sheet, roll or directly laminated on your chosen substrate.

Sold in Linear Metres with a Film Width of 1250mm

For orders over 20m please contact us for an accurate shipping quote

Further Information

Diamond Coatings also offer a wide range of coated films and we have now extended our film product range, to offer a high quality Anti-Reflective (AR) film, which we can provide by sheet, roll or directly laminated on your chosen substrate.

Our Transparent Diamox AR1617 film offers an enhanced level of higher transparency and is suitable for LCD’s, PDP’s, clear displays and touch panels, amongst others.

An additional benefit to our Diamox AR1617 Film is that it also boasts excellent Anti-Static and abrasion resistance properties, as well as being an anti-chemical material, all of which contribute to our film’s great performance.

Sold in Linear Metres with a Film Width of 1250mm

Typically, the film is best applied by lamination process but a hand-applied method of adhering this film successfully, can be seen below.

During our own internal trials, we also included a small addition of washing up liquid to the water, just to break the surface tension, which helped the application. Approximately 1 drop of washing up liquid per 250ml of water (this can be modified to suit your application, applying process and surface area etc).

The success of the application though will be very dependent on the environment it is being applied in and the surface cleanliness/condition of the substrate. Please note, after application “white/haze marks” can be seen. This is trapped moisture and should clear after 24-48hrs (maybe longer depending on conditions)

The above is processing advice, when lamination is not used – Diamond Coatings accept no liability for any subsequent processing.
